A+ Series® Air Coolers - Industrial Air Coolers - A+D
Low-Profile Dual Discharge Evaporator
Designed for refrigerated work rooms and product storage applications where low air velocity, limited ceiling height, and product protection are critical, Colmac Coil A+D Air Coolers combine a low-profile cabinet with dual-discharge airflow for uniform cooling throughout the space.
Available in capacities from 2 to 40 TR, the A+D is especially well suited for highly perishable products that can be sensitive to high air velocities and excessive moisture loss. Low-noise fans with high-efficiency motors provide dependable airflow while supporting a comfortable working environment.
Each A+D is custom engineered around the refrigeration load, room conditions, working fluid, airflow requirements, and installation constraints of the application.
The A+D distributes conditioned air from both sides of the unit, providing broad room coverage while maintaining relatively low discharge velocities. This makes it an ideal solution for processing and storage environments where conventional high-velocity airflow may be undesirable.
Key Benefits
Capacity range from 2–40 TR
Low-profile configuration for rooms with limited ceiling height
Dual-discharge airflow for broad room coverage
Low-velocity airflow for highly perishable products
Helps reduce direct high-velocity air exposure to products and personnel
Low-noise fans with high-efficiency motors
Multiple coil material combinations
Custom engineered for application-specific refrigeration and airflow requirements
Materials of Construction
Tube Material
Aluminum
304 stainless steel tubing
316 stainless steel tubing
Fin Material
Aluminum
Epoxy coated aluminum
304 stainless steel
316 stainless steel
Casing Material
G-235 galvanized steel
304 stainless steel
316 stainless steel
Defrost Options
Air
Hot Gas
Electric
Features
Low-Profile Configuration
Designed specifically for applications where ceiling clearance is limited, helping maximize usable storage and processing space while providing industrial refrigeration capacity up to 35 TR.
Full-Coverage Drain Pan
Designed to collect condensate and defrost water across the complete underside of the evaporator.
Hinged Fan Panels
Standard hinged fan panels improve access to fans and internal components for inspection and maintenance.
Flexible Coil Construction
Multiple tube and fin material combinations allow the evaporator to be configured for different refrigerants, sanitation requirements, corrosion environments, and operating temperatures.
Washdown duty motors
Certifications & Warranties
ASME "U" Stamp
ASME Section VIII requirements for pressure-containing equipment
CRN/CSA
Canadian Registration Number (CRN) and CSA certifications available for applications requiring compliance with Canadian pressure vessel and refrigeration equipment regulations
UL 207
UL 207 standards for refrigerant-containing components and accessories, verifying compliance with recognized refrigeration system safety requirements.
Warranty
Colmac Coil warrants its products to be free from defects in materials and workmanship under normal operating conditions. Standard warranty coverage includes repair or replacement of defective components in accordance with Colmac warranty terms. Pressure-bearing stainless steel coil components manufactured in accordance with ASME B31.5 are eligible for extended warranty coverage of up to five years from shipment date.
Applications
Fresh Produce
Meat Processing
Poultry Processing
Seafood Processing
Dairy Processing
Cheese Processing
Prepared Foods
Produce Packing Rooms
Refrigerated Work Rooms
Product Staging Areas
Other Temperature-Sensitive Food Applications
